Overview
Grade 316 stainless steel is a dependable and versatile material used across various industries. It is part of the austenitic stainless steel family and contains chromium, nickel and molybdenum, which give it greater corrosion resistance compared with 304 stainless steel.
Because of this, 316 stainless steel material is often chosen for environments where salt, chemicals or high moisture are present. It is also straightforward to form, machine and weld, making it practical for engineers who need both performance and ease of fabrication.
At Kormax, we supply 316 stainless steel in standard forms such as round bar and sheet, with custom sizes available on request. Every delivery is backed by batch certification and ISO-accredited quality systems.
316 stainless steel suppliers recommend this grade where safety, hygiene and durability cannot be compromised. Typical applications include:
Common Applications
Marine fittings and components
Pharmaceutical and chemical processing systems
Food and beverage manufacturing equipment
Medical instruments and surgical devices
Architectural and coastal structures
Heat exchangers and tanks
Key Features
Outstanding corrosion resistance in chloride-rich and acidic environments
Excellent strength and durability under high pressure and heat
Good formability, machinability, and weldability
Maintains mechanical integrity at temperatures up to ~800 °C
Non-magnetic in annealed condition; slightly magnetic when cold worked
Material Profile
When evaluating engineered materials solutions, understanding the main properties of 316 stainless steel material helps ensure the right fit for the job. This grade balances strength, corrosion resistance and stability at high temperatures.
Chemical Composition
The corrosion resistance of grade 316 stainless steel comes from its alloy content. The addition of molybdenum helps it stand up to saltwater and acidic environments better than other stainless steel grades, such as 304.
(Typical Composition %)
| Element | Symbol | Value |
| Carbon | C | ≤0.08 |
| Silicon | Si | ≤1.0 |
| Manganese | Mn | ≤2.0 |
| Phosphorus | P | ≤0.045 |
| Sulfur | S | ≤0.03 |
| Chromium | Cr | 16–18 |
| Nickel | Ni | 10–14 |
| Molybdenum | Mo | 2–3 |
Mechanical Properties
Engineers rely on 316 stainless steel material for its strength. Its performance under load makes it suitable for pressure systems, fabrication work, and metal casting environments.
| Property | Value |
| Tensile Strength | ≥ 515 MPa |
| Yield Strength | ≥ 205 MPa |
| Elongation | ≥ 40% (A50mm) |
| Hardness | ≤ 217 HB |
Tolerances Chart
When working with 316 Stainless Steel, dimensional accuracy is important. Kormax products are manufactured to ASTM A276 / A479 with ISO H-tolerances, the same rigorous approach we apply across our casting alloys and other engineered metals.
| Diameter (mm) Range | Tolerance Class | Tolerance (mm) |
| Up to 19.05 | H9 | +0 / -0.036 |
| 20 and above | H11 | +0 / -0.090 to -0.18 depending on size |
Manufactured to ASTM A276 / A479 with ISO H-tolerances.
Sizes & Availability
Kormax supplies 316 stainless steel round bar in a wide range of diameters. For projects requiring non-standard sizes, we can provide sourcing support alongside our metal casting services. This ensures engineers receive the material they need without delays.
Standard sizes available on request.
Round Bars
| Diameter (mm) | KG per Metre | Tolerance | Length (m) |
| 5.00 | 0.16 | H9 | 3 |
| 6.00 | 0.23 | H9 | 3 |
| 6.35 | 0.26 | H9 | 3 |
| 7.94 | 0.40 | H9 | 3 |
| 8.00 | 0.40 | H9 | 3 |
| 9.53 | 0.57 | H9 | 3 |
| 10.00 | 0.63 | H9 | 3 |
| 12.70 | 1.01 | H9 | 3 |
| 15.88 | 1.59 | H9 | 3 |
| 16.00 | 1.61 | H9 | 3 |
| 19.05 | 2.27 | H9 | 3 |
| 20.00 | 2.5 | H9 | 3 |
| 22.23 | 3.07 | H9 | 3 |
| 25.40 | 4.04 | H11 | 3 |
| 28.58 | 5.08 | H9 | 3 |
| 30.00 | 5.61 | H9 | 3 |
| 31.75 | 6.32 | H11 | 3 |
| 35.00 | 7.62 | H9 | 3 |
| 38.10 | 9.10 | H11 | 3 |
| 44.45 | 12.38 | H11 | 3 |
| 45.00 | 12.6 | H9 | 3 |
| 50.80 | 16.17 | H11 | 3 |
| 57.15 | 20.35 | H9 | 3 |
| 63.50 | 25.27 | H11 | 3 |
| 76.20 | 36.39 | H11 | 3 |
| 80.00 | 39.81 | H9 | 3 |
| 88.90 | 49.16 | H9 | 3 |
| 100.00 | 62.2 | H11 | 3 |
| 101.60 | 64.70 | H11 | 3 |
| 114.30 | 81.27 | H11 | 3 |
| 127.00 | 100.33 | H11 | 3 |
| 152.40 | 145.57 | H11 | 3 |
| 203.20 | 256.84 | H11 | 3 |
| 254.00 | 401.31 | H11 | 3 |
* Custom grades and sizes available by request.
Explore More Stainless Steel Grades
Looking for an alternative? Explore our broader range of stainless steel materials, including:
Kormax is your reliable stainless steel supplier, helping engineers source the right materials for lasting performance.
